| Access control list (acl): | Jā |
| Backup button: | Jā |
| Backup features: | Cloud/iSCSI LUN |
| Backup function: | Jā |
| Browser supported: | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
| Vendor homepage: | https://www.qnap.com/en/product/ts-453e |
| Unit box length: | 0.305 |
| Unit calculated volume: | 0.02689 |
| Unit box width: | 0.25 |
| Units per shipping box: | 2 |
| Unit box height: | 0.32 |
| Description: | TS-453E Dual 2.5GbE, 8GB RAM, and long-term availability
The TS-453E features 2.5GbE connectivity, 8GB RAM, and M.2 slots for NVMe SSD caching to deliver high performance for applications such as surveillance systems, virtual machines, file servers or backup servers. Dual HDMI outputs also provide direct multimedia playback and robust surveillance monitoring. QNAP will provide long-term availability and support for the TS-453E, providing a great choice for businesses requiring matching NAS models deployed in multiple locations.
Processor IntelĀ® CeleronĀ® J6412 quad-core processor (burst up to 2.6GHz)
RAM Onboard 8GB (non-expandable)
Encryption The IntelĀ® AES-NI encryption engine boosts encryption performance while maintaining the confidentiality of NAS data.
USB ports • 2 x USB 3.2 Gen2 • 2 x USB 2.0
Long-term availability The TS-453E is powered by an IntelĀ® CeleronĀ® J6412 processor and will be available and supported for |
| Unit calculated weight: | 4.09 |
| Server operating systems supported: | Windows Server 2008 R2/Windows Server 2012/Windows Server 2012 R2/Windows Server 2016/Windows Server 2019 |
| Share folder access right management: | Jā |
| Share folder: | 512 |
| Package depth: | 520 |
| Package height: | 320 |
| Product colour: | Black |
| Units per pallet: | Nav |
| Number of power supply units: | 1 |
| Windows operating systems supported: | Windows 10/Windows 11/Windows 7/Windows 8 |
| Ac input voltage: | 100 - 240 |
| Fan voltage: | 12 |
| Storage drive sizes supported: | 2.5/3.5/M.2 |
| Weight: | 3000 |
| Width: | 160.2 |
| Cables included: | AC/LAN (RJ-45) |
| External power adapter: | Jā |
| Package type: | Box |
| Raid support: | Jā |
| Hdmi version: | 1.4b |
| Usb 2.0 ports quantity: | 2 |
| Usb 3.2 gen 2 (3.1 gen 2) type-a ports quantity: | 2 |
| Usb port: | Jā |
| Chassis type: | Tower |
| Cooling type: | Active |
| Fan diameter: | 120 |
| Led indicators: | LAN/Power/Status |
| Number of fans: | 1 |
| Raid rebuild: | Jā |
| Raid levels: | 0/1/10/5/6/JBOD |
| Auto-rebuild: | Jā |
| Bad block scan: | Jā |
| Disk roaming: | Jā |
| Hot-swap drive bays: | Jā |
| Installed storage drive type: | No |
| Number of m.2 (m & b) slots: | 2 |
| Number of storage drives supported: | 4 |
| Online raid expansion: | Jā |
| Online raid migration: | Jā |
| Hdmi ports quantity: | 2 |
| Power cables quantity: | 1 |
| On/off switch: | Jā |
| Password authentication: | Jā |
| Reset button: | Jā |
| S.m.a.r.t. support: | Jā |
| Disk scan: | Jā |
| Hot spare: | Jā |
| Management protocols: | SNMP V2/V3 |
| Height: | 168.5 |
| Power consumption (sleep): | 15.78 |
| Power consumption (typical): | 33.88 |
| Power supply location: | External |
| Power supply unit (psu) capacity: | 90 |
| Depth: | 220.5 |
| Storage drives installed: | No |
| Supported file systems: | exFAT/ext3/ext4/FAT32/HFS+/NTFS |
| Supported storage drive interfaces: | M.2,Serial ATA III |
| Supported storage drive types: | HDD & SSD |
| Total installed storage capacity: | Nav |
| Processor boost frequency: | 2.6 |
| Processor cores: | 4 |
| Processor family: | IntelĀ® CeleronĀ® |
| Processor frequency: | 2 |
| Processor manufacturer: | Intel |
| Processor model: | J6412 |
| Processor threads: | 4 |
| Flash memory: | 4000 |
| Internal memory: | 8 |
| Maximum ram supported: | 8 |
| Dhcp server: | Jā |
| Dynamic dns (ddns): | Jā |
| Ethernet lan: | Jā |
| Ethernet lan data rates: | 10/100/1000/2500 |
| Iscsi support: | Jā |
| Jumbo frames support: | Jā |
| Wake-on-lan ready: | Jā |
| Ethernet lan (rj-45) ports: | 2 |
| Security algorithms: | FIPS 140-2/HTTPS/SNMPv2/SNMPv3/SSH |
| Package weight: | 3610 |
| Package width: | 307 |
| Built-in ftp server: | Jā |
| Buzzer: | Jā |
| Device class: | Small & Medium Business |
| Operating relative humidity (h-h): | 5 - 95 |
| Operating temperature (t-t): | 0 - 40 |
| Storage relative humidity (h-h): | 5 - 95 |
| Storage temperature (t-t): | -20 - 70 |
| Warranty period: | 3 |
| Model name: | TS-453E |
| Snapshot: | Jā |
| System log: | Jā |
| Type: | NAS |
| Usb copy function: | Jā |
| Linux operating systems supported: | Ubuntu 14.04 |
| Mac operating systems supported: | Mac OS X 10.10 Yosemite/Mac OS X 10.11 El Capitan/Mac OS X 10.12 Sierra/Mac OS X 10.13 High Sierra/Mac OS X 10.15 Catalina/Mac OS X 10.15.3 Catalina |
| Operating system installed: | QNAP QTS |
| Operating system version: | 5.0.1 |
| Other operating systems supported: | Solaris 10 |
| Summary: | QNAP TS-453E. Type: NAS. Chassis type: Tower. Device class: Small & Medium Business. Processor family: IntelĀ® CeleronĀ®, Processor model: J6412, Processor frequency: 2 GHz. Internal memory: 8 GB. Total installed storage capacity: 0 TB. Operating system installed: QNAP QTS |
