| Description: | People & Vehicle Analytics Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.
Human & Vehicle Classification Distinguish humans and vehicles from other objects and receive more accurate event notifications.
Smart Video Enhancement Technology True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.ā–³
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless o |
| Supported graphics resolutions: | 1280 x 720 (HD 720)/1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2560 x 1440/2688 x 1520 |
| International protection (ip) code: | IP67 |
| Vendor homepage: | https://www.tp-link.com/ae/business-networking/vigi-network-camera/insight-s245/ |
| Camera pan control: | Jā |
| Unit calculated volume: | 0.004096 |
| Day/night mode: | Jā |
| Digital wide dynamic range (dwdr): | Jā |
| Highlight compensation (hlc): | Jā |
| Remote viewing: | Jā |
| Form factor: | Dome |
| Housing material: | Metal |
| Connectivity technology: | Wired |
| Model: | InSight S245 |
| Unit calculated weight: | 0.909 |
| Maximum resolution: | 2688 x 1520 |
| Summary: | TP-Link InSight S245. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Lens viewing angle, horizontal: 110°, Lens viewing angle, vertical: 58.1°, Lens viewing angle, diagonal: 133.5°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 64 m, Observe distance: 27 m, Recognize distance: 13 m |
| Units per shipping box: | 1 |
| Ik code: | IK10 |
| Weatherproof: | Jā |
| Mounting type: | Ceiling |
| Ethernet lan (rj-45) ports: | 1 |
| Alert notification type: | Push notification |
| Dynamic range: | 120 |
| Infrared (ir) cut-off filter: | Jā |
| Maximum operating distance: | 64 |
| Placement supported: | Outdoor |
| Wi-fi: | No |
| Compatible memory cards: | MicroSD (TransFlash) |
| Maximum memory card size: | 512 |
| Dc-in jack: | Jā |
| Image quality adjustment: | Brightness/Contrast/Mirror/Saturation/Sharpness |
| Identify distance: | 6 |
| Maximum aperture number: | 1.6 |
| Observe distance: | 27 |
| Recognize distance: | 13 |
| Product colour: | White |
| Protection features: | Waterproof |
| Type: | IP security camera |
| Wide dynamic range (wdr): | Jā |
| Minimum illumination: | Nav |
| Tilt angle range: | 0 - 75 |
| Optical sensor size: | 1/2.7 |
| Progressive scan: | Jā |
| Sensor type: | CMOS |
| Detect distance: | 64 |
| Fixed focal length: | 2.8 |
| Lens viewing angle, vertical: | 58.1 |
| Lens viewing angle, horizontal: | 110 |
| Lens viewing angle, diagonal: | 133.5 |
| Camera tilt control: | Jā |
| Camera shutter speed: | 1/3 to 1/10000 |
| Led type: | IR/White |
| Night vision: | Jā |
| Back light compensation (blc): | Jā |
| Bit rate: | Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264 |
| Bit rate control: | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Total megapixels: | 4 |
| Video compression formats: | H.264/H.264+/H.265/H.265+ |
| Video recording: | Jā |
| Audio formats supported: | G.711 A-law |
| Audio input channels: | 1.0 |
| Audio output channels: | 1.0 |
| Audio system: | 2-way |
| Bit rate range: | 0 - 64 |
| Built-in microphone: | Jā |
| Built-in speaker(s): | Jā |
| Number of microphones: | 1 |
| Sample rate: | 8 |
| Bluetooth: | No |
| Ethernet lan: | Jā |
| Live view: | Jā |
| Networking standards: | IEEE 802.3af/IEEE 802.3at |
| Supported network protocols: | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
| Built-in siren: | Jā |
| Detection distance: | 64 |
| Digest authentication: | Jā |
| Https encryption: | Jā |
| Human and vehicle targets classification: | Jā |
| Intelligent video surveillance (ivs) system features: | Abnormal sound detection/Crossing line/Human detection/Intrusion/Line crossing detection/Moving object/Region entrance detection/Region exiting detection/Scene change/Vehicle detection |
| Ip address filtering: | Jā |
| Mirror: | Jā |
| Motion sensor: | Jā |
| Password protection: | Jā |
| Video motion detection: | Jā |
| Cloud-managed: | Jā |
| Reset button: | Jā |
| Web browser: | Jā |
| Web-based management: | Jā |
| Dc output voltage: | 12 |
| Power consumption (power over ethernet (poe)): | 12.52 |
| Power source type: | DC,PoE |
| Operating relative humidity (h-h): | 0 - 95 |
| Operating temperature (t-t): | -30 - 60 |
| Storage relative humidity (h-h): | 0 - 95 |
| Storage temperature (t-t): | -40 - 60 |
| Depth: | 122 |
| Height: | 89 |
| Weight: | 620 |
| Width: | 122 |
| Manual: | Jā |
| Number of cameras: | 1 |
| Unit box height: | 0.16 |
| Unit box length: | 0.16 |
| Unit box width: | 0.16 |
