| Model: | O11DMIV2FX |
| Units per shipping box: | 1 |
| Summary: | Lian Li 011 Dynamic Mini O11D mini V2 Flow. Form factor: Mini Tower, Type: PC, Product colour: Black. Front fans diameters supported: 120 mm, Side fans installed: 2x 120 mm, Side fans diameters supported: 120 mm. Supported HDD sizes: 2.5,3.5". Width: 273.3 mm, Depth: 423.6 mm, Height: 391.9 mm |
| Audio output: | Jā |
| On/off button: | Jā |
| Product colour: | Black |
| Side window: | Jā |
| Supported motherboard form factors: | ATX/micro ATX/Mini-ATX |
| Type: | PC |
| Power supply included: | No |
| Model name: | O11 DYNAMIC MINI V2 FLOW |
| Vendor homepage: | https://lian-li.com/product/o11-dynamic-mini-v2/ |
| Anti-dust filter: | Jā |
| Cable management: | Jā |
| Form factor: | Mini Tower |
| Material: | Aluminium/Mesh/Tempered glass |
| Maximum cpu cooler height: | 160 |
| Maximum graphics card length: | 400 |
| Maximum psu length: | 200 |
| Number of 2.5" bays: | 4 |
| Number of 3.5" bays: | 2 |
| Number of expansion slots: | 5 |
| Unit calculated volume: | 0.0913 |
| Unit calculated weight: | 12.6 |
| Description: | SLIGHTLY BIGGER CASE, WAY MORE CAPACITY Only 2L larger than the original O11D Mini, but redesigned for greater hardware compatibility and improved airflow.
ATX BACK-CONNECT MOTHERBOARD SUPPORT The case offers broad motherboard support, including standard ATX, M-ATX, and Mini-ITX form factors. For users seeking next-level cable management and cleaner builds, Back-Connect compatibility is exclusively available with ATX Back-Connect motherboards.
ANGLED BASE FOR DIRECT GPU AIRFLOW A 10° slanted bottom channels cool air directly to the GPU for better cooling performance and a cleaner look.
THE FLOW EDITION IS PRE-INSTALLED WITH FIVE REVERSE-BLADE FANS Flow versions come with five reverse blade PWM fans—three at the bottom and two on the side, for strong, silent airflow right out of the box.
OPTIMIZED FOR GPU COOLING The slanted bottom design and pre-installed fans channel airflow directly to the GPU, enhancing cooling efficiency. In thermal testing under identical |
| Usb 3.0: | 2 |
| Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity: | 2 |
| Usb 3.2 gen 2 (3.1 gen 2) type-c ports quantity: | 1 |
| Bottom fans diameters supported: | 120 |
| Bottom fans installed: | 3x 120 mm |
| Front fans diameters supported: | 120 |
| Number of bottom fans supported (max): | 3 |
| Number of rear fans supported (max): | 1 |
| Number of side fans supported (max): | 2 |
| Number of top fans supported (max): | 3 |
| Rear fans diameters supported: | 120 |
| Side fans diameters supported: | 120 |
| Side fans installed: | 2x 120 mm |
| Supported hdd sizes: | 2.5/3.5 |
| Depth: | 423.6 |
| Height: | 391.95 |
| Width: | 273.3 |
| Unit box height: | 0.47 |
| Unit box length: | 0.525 |
| Unit box width: | 0.37 |
| Units per pallet: | Nav |
