| Unit box width: | 0.155 |
| Power protection features: | Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage |
| Total power: | 1300 |
| Package weight: | 6800 |
| Unit box height: | 0.255 |
| Package height: | 152 |
| Eps version: | 2.92 |
| Efficiency: | 94.5 |
| Max output current (+3.3v): | 25 |
| Max output current (+5v): | 25 |
| Max output current (+5vsb): | 3.5 |
| Max output current (-12v): | 0.5 |
| Peak power: | 1400 |
| Units per shipping box: | 1 |
| Package width: | 253 |
| Sustainability compliance: | Jā |
| Description: | CUTTING EDGE TECHNOLOGIES AND PERFORMANCE The be quiet! Dark Power Pro 13 1300W offers 80 PLUSĀ® Titanium efficiency and world-class performance due to fully digital control and a frameless fan concept. With the latest PCIe 5.0 compatibility it is predetermined as the ATX 3.0 power supply for your next-gen graphics card. - 80 PLUS Titanium efficiency (up to 94.4%)
- ATX 3.0 PSU with full support for PCIe 5.0 GPUs and GPUs with 6+2 pin connectors
- Handles massive power excursions
- Fully digital control and Active Rectifier + full bridge LLC technology for unmatched signal stability
- Improved and patented frameless Silent Wings fan for virtually inaudible operation at ordinary loads
- Full mesh PSU front with funnel-shaped air inlet
- Overclocking key switches between six 12V rails and one massive 12V rail
- Japanese 105°C capacitors ensure highest stability and reliability
- 2 PCIe 5.0 12VHPWR 600W and 6 PCIe 6+2 connectors for overcl
|
| Unit calculated volume: | 0.0166 |
| Model name: | Dark Power Pro 13 1300W |
| Atx power connector (20+4 pin): | Jā |
| Unit box length: | 0.42 |
| Vendor homepage: | https://www.bequiet.com/en/powersupply/4394 |
| Cabling type: | Fully-Modular |
| Unit calculated weight: | 6.6 |
| Package depth: | 417 |
| Input current: | 15 - 9 |
| Max output current (+12v1): | 35 |
| Power factor: | 0.99 |
| Max output current (+12v3): | 40 |
| Max output current (+12v4): | 40 |
| Max output current (+12v2): | 35 |
| Summary: | be quiet! Dark Power Pro 13 | 1300W. Total power: 1300 W, AC input voltage: 115 - 240 V, Peak power: 1400 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 500,600,750,800,900,950,1050 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Titanium. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Cables included: CPU, PCIe, Peripheral (Molex), SATA |
| Cpu power cable length: | 700 |
| Eps power connector (4+4 pin): | Jā |
| Eps power connector (8-pin): | Jā |
| Motherboard power cable length: | 600 |
| Motherboard power connector: | 20+4 pin ATX |
| Number of pata power connectors: | 5 |
| Number of sata power connectors: | 16 |
| Pci express connector: | Jā |
| Pci express power cable length: | 600 |
| Pci express power connectors (6+2 pin): | 6 |
| Ac input frequency: | 50 - 60 |
| Ac input voltage: | 115 - 240 |
| Combined power (+12v): | 1300 |
| Combined power (+3.3v): | 150 |
| Combined power (+5v): | 150 |
| Combined power (+5vsb): | 17.5 |
| Combined power (-12v): | 6 |
| Hold time: | 18 |
| Atx version: | 3.0 |
| Bearing technology: | FDB |
| 80 plus certification: | 80 PLUS Titanium |
| Peripheral (molex) power cable length: | 1050/600/750/900 |
| Sata power cable length: | 1050/500/600/750/800/900/950 |
| Products per shipping (inner) case: | 2 |
| Shipping (inner) case height: | 283 |
| Shipping (inner) case length: | 440 |
| Shipping (inner) case net weight: | 14400 |
| Shipping (inner) case width: | 325 |
| Warranty period: | 10 |
| Mean time between failures (mtbf): | 100000 |
| Noise level: | 23.2 |
| Power supply unit (psu) form factor: | ATX |
| Purpose: | PC |
| Cooling type: | Active |
| Fan diameter: | 135 |
| Number of fans: | 1 |
| Product colour: | Black |
| Cable tie(s) included: | Jā |
| Cables included: | CPU,PCIe,Peripheral (Molex),SATA |
| Compliance certificates: | CCC/CE/Federal Communications Commission (FCC)/UKCA |
| Depth: | 200 |
| Height: | 86 |
| Weight: | 2410 |
| Width: | 150 |
